TERN Tern Link Folding Bikes

Information

The Link B7 is built for exploring. It folds down small in ten seconds, so you can bring it with you anywhere—on the subway, in your car, or even store it indoors at night. With 7-speed gearing, eyelets for rear racks, and a height-adjustable telescopic handlepost, it packs a ton of versatility. Ride one and discover the convenience of Tern.

General Info
Speeds:
1 x 7
Weight:
12.1 kg (26.7 lb)
Gear Inches:
36" - 72" (2.86 - 5.72 m)
Frame Sizes:
One size
Folding Size:
39.5 × 80 × 73 cm (15.6 × 31.5 × 28.7 in)
Folding Time:
10 sec
Distance: Saddle to Pedal:
70 - 96 cm (27.6 - 37.8 in)
Suggested Rider Height:
142 - 190 cm (55.9 - 74.8 in)
Max Gross Vehicle Weight:
120 kg (264.6 lb)
Max Rider Weight:
105 kg (231.5 lb)

Frame
Frame:
Tern Link, aluminum, FBL 2 Joint, 3 patented technologies
Fork:
Hi-tensile steel

Cockpit
Handlepost:
Q-Lock, forged aluminum, patented
Stem:
Telescope, 6061-AL
Headset:
Cartridge
Handlebar:
Flat bar, 6061-AL
Grips/Bar Tape:
BioLogic Ergo, Kraton
Saddle:
Velo Comfort
Seatpost:
SuperOversize, 6061-AL, micro-adjust clamp
Seatpost Clamp:
SuperOversize, 6061-AL

Brakes
Front Brake:
V, aluminum, linear spring
Rear Brake:
V, aluminum, linear spring
Brake Levers:
V, aluminum bracket/lever
Brake Cable & Housing:
Anti-compression housing, slick cables

Wheels
Front Hub:
Mini, aluminum
Rear Hub:
7 spd, aluminum
Spokes & Nipples:
Steel / Stainless steel
Rims:
Aluminum
Tyres:
Road Cruiser, 47-406, KevlarGuard, puncture protection

Transmission
Shifter(s):
Shimano, 1 x 7 spd, twist
Rear Derailleur:
Shimano Tourney
Crankset:
Forged 6061 aluminum, 52T
Cassette/Freewheel:
Shimano 7 spd, 14-28T
Bottom Bracket:
Two-piece
Chain:
7 spd
Pedals:
Folding, alloy body
Shifter Cable & Housing:
SP

Bells & Whistles
Bell:
Aluminum
Kickstand:
Deluxe center mount
Clip System:
Magnetix 2.0
Luggage Socket:
No
Fenders:
Opt: RP Chromeplastic, stainless hardware
