Merida One Sixty 700 Mountain Bike My24

Information

Bike Radar / MBUK gave Merida double honours crowning the One-Sixty 6000 Enduro bike of the year and the One-Forty 700 Trail bike of the year. Of the One-Sixty they said: "it was the Merida’s proportions, supportive suspension and electrifying ride feel that finally clinched it.“The fun we had riding some of the gnarliest trails around Dolceacqua, skimming over jagged rocks and drifting loose turns, meant it had to be the winner.” The One-Sixty 700 gets all the cutting edge enduro performance of Merida's radical new design but with a high-value and fully featured all-aluminium frame. That means hard-hitting modern geometry with the new FAST kinematic suspension that delivers a chaos taming ride alongside quality Marzocchi and Fox suspension. Shimano’s proven 12-speed Deore drivetrain means reliable shifts time after time, while four-piston brakes make short work of keeping everything under control. The One-Sixty is a radical, all-new design that pushes Merida's hard-hitting enduro platform to new heights. Just as well, because once it’s there it’s ready to rip the longest, toughest descents too. Merida's new suspension system uses a flexstay design with an adjustable rocker, so whether you choose to run it as a full 29er (162mm travel) or mixed 29/27.5” setup (171mm travel), the geometry is preserved. There’s a radically steep 79° seat tube angle for goat-like climbing and slack 64° head angle plus 170mm fork to deal with downhill trail chaos. New sizing allows riders to run a longer or shorter reach frame independently of their height, while suspension becomes more progressive as you size up, all with long-travel dropper posts. Wire Port cable routing plus reliable threaded bottom bracket round out the package, while carbon frame models offer on-board tool storage and FidLock magnetic bottle cages.

• Frame: Lite Aluminium, Next Generation enduro geometry, internal cable routing, long seat post insert depth. Boost axles standard, threaded BB, trail mount and bottle bosses, flip chip for mullet or 29er. max tyre size - 2.5"
• Rear Shock: Marzocchi Bomber Air; platform
• Fork: Marzocchi Z1; Air; 170mm travel; Tapered; 44mm fork offset; Max tyre size: 29" x 2.6"
• Headset: Acros ICR external neck; Upper and lower IPS sealing
• Stem: Merida Expert eTRII; aluminium; 35mm diameter; 0 degree rise - Stem length: 40mm (all sizes). GoPro & Supernova mount point.
• Handlebar: Merida Expert TR II; aluminium; 780mm wide; XS/S 18mm rise; M/L/XL 30mm rise
• Grip: Merida Expert EC
• Brake Type: Hydraulic disc
• Front Brake: SRAM DB8 4 piston hydraulic disc brake caliper with SRAM CenterLine 200mm rotor
• Rear Brake: SRAM DB8 4 piston hydraulic disc brake caliper with SRAM CenterLine 200mm rotor
• Tyres: Maxxis DHR II; 27.5" x 2.4" for XS/S & M; 29" x 2.4" for L & XL; Kevlar bead, folding; TR DD 3C MaxxTerra
• Wheel Size: 29" / 27.5"
• Rim: Merida Expert TR II; 28mm inner rim width; aluminium; Tubeless ready (tubeless tape and valves not included); Rear 27.5" for XS/S & M, 29" for L & XL
• Front Hub: Novatec SL-Team D041SB-B15; 110x15mm; 32 spokes; 6 Bolt
• Rear Hub: Novatec SL-Team D462SB-S3S; 148x12mm; 32 spokes; 6 Bolt
• Speeds: 12
• Rear Derailleur: SRAM NX Eagle
• Shift Levers: SRAM NX
• Chain: SRAM SX Eagle
• Cassette: SRAM PG-1210 Eagle; 10-50 teeth; 12 speed
• Chainset: SRAM NX Eagle DUB; 32 tooth chainset. Crank length: 170mm all sizes
• Bottom Bracket: SRAM DUB BSA 73mm wide
• Pedals: Not included
• Saddle: Merida Expert SL with V-mount; including Merida minitool
• Seat Post: Merida Team TR; 34.9mm diameter; in-line; all sizes 30-230mm seat post travel
